88xnm Module
We provide fiber coupled laser diode modules at 88xnm with various power options. Featuring high brightness, excellent electro-optical conversion, and exceptional reliability, these modules have been widely adopted in the market and consistently deliver outstanding performance.
| No. | Product Code | Wavelength(nm) | Output Power(W) | Operating Current(A) | Operating Voltage(V) | Core Diameter/Cladding Diameter(μm) | Mode |
| 1 | TL-880-01036E | 880 | 10 | 105 | MM | ||
| 2 | TL-880-01536E | 880 | 15 | 105 | MM | ||
| 3 | TL-885-02036G | 885 | 20 | 200 | MM | ||
| 4 | TL-885-12036G | 885 | 120 | ≤15 | 200/220 | MM | |
| 5 | TL-888-02036G | 888 | 20 | 200 | MM | ||
| 6 | TL-888-06536G | 888 | 65 | 13 | 9.5 | 200 | MM |
| 7 | TL-888-12036G | 888 | 120 | 12 | 19 | 200/220 | MM |
| 8 | TL-888-12036I | 888 | 120 | 12 | 19 | 400/440 | MM |
| 9 | TL-888-18036G | 888 | 180 | 12 | 28 | 200/220 | MM |
| 10 | TL-888-23036G | 888 | 230 | 13 | 31 | 200/220 | MM |
| 11 | TL-888-30036G | 888 | 300 | 13 | 200/220 | MM | |
| 12 | TL-888-50036G | 888 | 500 | 15 | 200/220 | MM |
