VCSEL Chip
We provide a range of products in various wavelengths to our customers in the form of VCSEL chips. Known for their high quality, reliability, and excellent conversion efficiency, these products have been widely adopted in the market and consistently deliver outstanding performance.
| PN | Description | Description | Wavelength (nm) | Output Power(mW) | Operating Voltage（V) | Operating Mode | Mode |
| 1 | TL-660-A0X040 | 660nm VCSEL | 660 | LP-SM | |||
| 2 | TL-660-A02040 | 660nm VCSEL | 660 | 2 | MM | ||
| 3 | TL-660-A05040 | 660nm VCSEL | 660 | 5 | MM | ||
| 4 | TL-660-A07040 | 660nm VCSEL | 660 | 7 | MM | ||
| 5 | TL-670-A04040 | 670nm VCSEL | 670 | 4 | MM | ||
| 6 | TL-670-A09040 | 670nm VCSEL | 670 | 9 | MM | ||
| 7 | TL-670-A12040 | 670nm VCSEL | 670 | 12 | MM | ||
| 8 | TL-680-A05040 | 680nm VCSEL | 680 | 5 | MM | ||
| 9 | TL-680-A12040 | 680nm VCSEL | 680 | 12 | MM | ||
| 10 | TL-680-A18040 | 680nm VCSEL | 680 | 18 | MM | ||
| 11 | TL-680-A50040 | 680nm VCSEL | 680 | 50 | MM | ||
| 12 | TL-680-A60040 | 680nm VCSEL | 680 | 60~200 | CW | MM | |
| 13 | TL-730-A05040 | 730nm VCSEL | 730 | 5 | MM | ||
| 14 | TL-760-E03040 | 760nm VCSEL | 760 | 0.3 | 2.1 | CW | SM |
| 15 | TL-761-A01040 | 761nm VCSEL | 761 | 1 | MM | ||
| 16 | TL-795-E01040 | 795nm VCSEL | 795 | 0.1 | 2.3 | CW | SM |
| 17 | TL-795-E12040 | 795nm VCSEL | 795 | 1.2 | 2.3 | CW | SM |
| 18 | TL-795-E18040 | 795nm VCSEL | 795 | 1.8 | 2.3 | CW | SM |
| 19 | TL-808-A0X040 | 808nm VCSEL | 808 | LP-SM | |||
| 20 | TL-808-004040 | 808nm VCSEL | 808 | 4 | 5 | QCW | SM |
| 21 | TL-808-A05040 | 808nm VCSEL | 808 | 5~500 | MM | ||
| 22 | TL-808-001040 | 808nm VCSEL | 808 | 1W~6W | MM | ||
| 23 | TL-808-004040 | 808nm VCSEL | 808 | 4W | SM | ||
| 24 | TL-810-001040 | 810nm VCSEL | 810 | 1W~3W | MM |
| PN | Description | Description | Wavelength (nm) | Output Power(mW) | Operating Voltage（V) | Operating Mode | Mode |
| 25 | TL-850-A05040 | 850nm VCSEL | 850 | 0.5~2 | SM | ||
| 26 | TL-850-E05040 | 850nm VCSEL | 850 | 5~500 | MM | ||
| 27 | TL-850-001040 | 850nm VCSEL | 850 | 1W~6W | MM | ||
| 28 | TL-880-A01040 | 880nm VCSEL | 880 | 1 | SM | ||
| 29 | TL-895-E02040 | 895nm VCSEL | 895 | 0.2 | 2.3 | CW | SM |
| 30 | TL-895-A01040 | 895nm VCSEL | 895 | 1 | 2.3 | CW | SM |
| 31 | TL-895-E15040 | 895nm VCSEL | 895 | 1.5 | 2.3 | CW | SM |
| 32 | TL-905-007040 | 905nm VCSEL | 905 | 7 | MM | ||
| 33 | TL-905-030040 | 905nm VCSEL | 905 | 30 | 6.0 | 24.5 | MM |
| 34 | TL-905-070040 | 905nm VCSEL | 905 | 70 | MM | ||
| 35 | TL-905-150040 | 905nm VCSEL | 905 | 150 | MM | ||
| 36 | TL-905-300040 | 905nm VCSEL | 905 | 300 | 63 | 26 | MM |
| 37 | TL-940-A05040 | 940nm VCSEL | 940 | 5~500 | SM/MM | ||
| 38 | TL-940-001040 | 940nm VCSEL | 940 | 1W~9W | MM | ||
| 39 | TL-1060-A0X040 | 1060nm VCSEL | 1060 | LP-SM | |||
| 40 | TL-1064-A30040 | 1064nm VCSEL | 1064 | 30 | MM | ||
| 41 | TL-1064-003040 | 1064nm VCSEL | 1064 | 3W | MM |
