405nm Module

Wavelength 405nm/425nm
Detail

High-power fiber-coupled laser modules integrate semiconductor laser chips, precision fiber-coupling optics, thermal management, and electrical interfaces into a compact, ready-to-use package. They provide stable fiber output, high reliability, and easy system integration for demanding industrial and scientific applications.


405nm fiber-coupled laser modules are widely used in laser direct imaging (LDI), UV curing, precision micromachining, semiconductor processing, and scientific instrumentation. Owing to the high absorption of many polymers, resins, adhesives, coatings, and certain reflective metals at this wavelength, 405nm lasers are well suited for precision cutting, drilling, marking, engraving, and other fine material processing applications. Our products feature high reliability, excellent electro-optical efficiency, and stable long-term performance for both industrial and research applications.


Browse the products below to find the module that best fits your application. If you need detailed specifications, pricing, or assistance in selecting the appropriate configuration, please contact our sales and technical team.



No.
Product Code
Wavelength
(nm)
Output Power
(W)
Operating Current (A)
Operating Voltage (V)
Core Diameter (μm)
Mode
1
TL-405-A1036E
405
0.01
0.06
6
105
MM
2
TL-405-A1636A
405
0.16
0.17
5.5
50
MM
3
TL-405-A1636E
405
0.16
0.5
5.5
105
MM
4
TL-405-B3036E
405
0.3
0.325
4.5
105
MM
5
TL-405-B6036E
405
0.6
0.35
12
105
MM
6
TL-405-B7036E
405
0.7
　
　
105
MM
7
TL-405-00136E
405
1
0.625
5
105
MM
8
TL-405-00336E
405
3
1.8
4.7
105
MM
9
TL-405-00836E
405
8
　
　
105
MM
10
TL-425-00836E
425
8
0.65
20*2
105
MM
11
TL-405-01036E
405
10
3.5
24
105
MM
12
TL-405-01236E
405
12
0.5
25
105
MM
13
TL-425-01236N
425
12
0.8
17*2
150
MM
14
TL-405-02036E
405
20
7
24
105
MM
15
TL-405-02036I
405
20
　
　
400
MM
16
TL-405-04036E
405
40
10
24
105
MM
17
TL-405-05036I
405
50
　
　
400
MM
18
TL-405-06036E
405
60
14
24
105
MM
19
TL-405-08036E
405
80
14
24
105
MM
20
TL-405-10036E
405
100
20
24
105
MM
21
TL-405-20036K
405
200
1.7
65
800
MM



Note: Unless otherwise specified, all products are standard fiber-coupled laser modules. The package structure, output interface, fiber core diameter, and other key parameters can be customized according to specific application requirements.
